30W Street light system
Name | Description | ||
Led Rated power | 30W | LED light Anqel | 190 |
LED sourcinq brand | Purui | LED liqht Lumens (LM) | 150 |
Number's LED lamp bead | 30 | LED Bead temperature | 3000〜6000 |
Lumens of each bead(LM) | 180 | LED bead liftime(hours) | 50000 |
Product Lumens(LM) | 3000-4800LM | Conversion efficiency | >0.95 |
Display CRI | 78 | IP Waterproof class | IP65 |
Upper Pole dimater | 70/147mm | Working frequency(Hz) | / |
Output Current(A) | 1 | working temperature | -40t：-+70t： |
Output Voltaqe(V) | DC28/31V | Temperature suitable for product | -30t>+60t： |
Input Voltage(V) | DC12V | Working humidity | 15-90%RH |
Description of LED light:
1.Size：6m-70/140mm
2.Net Weight：110KG
3.Flange：280*280*14mm j
4.Ground cage280*280*61 OMM»
1.Materials：aluminium + solar tempering glass
2.solar panel：18V 80W( Germany solar cells)
3. LED ：30V 30W 3000-4800LM
4. Battery：GEL battery 80AH
5. Pole height：6-7.5m
6. Working time：8-12/day ,we can also set time base on your requirement，rainy days( 7〜10days )
7. Working temperature:-30t>+60t)
8. Charging time：6hours
9. Certificate：IS09001 ,IEC
10. light control and time control
11. Installation distance：every pole distance is 30-35m, if it is double road .every 60-70m to install one pole
