6-GFM-200AH  Battery Technical Instructions

Application Areas

• Solar Power System

Product Model

  Fixed Type VRLA GEL battery

• Installation

• Batteries are charged before out of the factory, in the transport installation process to guard against short circuit.

• Battery voltage is higher, in the installation and maintenance should use insulated tools to prevent electric shock.

• Connecting cable as short as possible to prevent excessive pressure drop.

• End connections in the installation and on-battery system, check the total voltage of  battery system and positive and negative, in order to ensure the correct installation.

  Maintenance

• Total float voltage exceeds (13.60 ± 0.20) × nV, (n refers to the number of cells) within the range should be adjusted, or affect battery life.

• Checking monthly single battery float voltage, and make a record, such as running for six months, float voltage difference exceeds 0.5V, you should contact the manufacturer, the manufacturers will deal.

• Checking once a year whether there is loosening the connecting portion, timely solve.

• Optimal ambient temperature 15 ℃ -25 ℃ get a longer life, the battery can be -40 ℃ -50 ℃ conditions.

• Try to avoid over discharge (discharge voltage is lower than the termination voltage) and overcharge (longer than the charging voltage float voltage), and the discharge should be charged as soon as possible, otherwise affect battery life.

• Do not use organic solvents and the application of soapy water batteries, avoid using dry cloth that is easy to produce static electricity to wipe the battery.

• For storage battery, disconnect the battery and charging equipment and the connecting portion of the load and keep the environment cool, dry and ventilated.
