100AH ，150AH,200AH Solar Battery

Voltage Per Unit

12

Capacity

100Ah@10hr-rate to 1.80V per cell @25°C

Weight

Approx. 30.0 Kg (Tolerance ±2%)

Internal Resistance

Approx. 5 mQ

Terminal

F12(M8)/F5(M8)

Max. Discharge Current

1000A(5 sec)

Design Life

12 years (floating charge)

Maximum Charging Current

30.0 A

C3 78.3AH

Reference Capacity

C5 88.0AH C10 100.0AH C20 105.2AH

Float Charging Voltage

13.6 V~13.8 V @25°C
Temperature Compensation: -3mV/°C/Cell

Cycle Use Voltage

14.6V-14.8V @25°C
Temperature Compensation: -4mV/°C/Cell

Discharge: -20°C~60°C

Operating Temperature Range

Charge: 0 °C~50 °C Storage: -20°C~60°C

Normal Operating Temperature Range

25°C 士 5°C

Self Discharge

RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25°C and then recharging is recommended. Monthly Self-discharge ratio is less than 3% at 25°C.Please charged batteries before using.

Container Material

A.B.S. UL94-HB, UL94-V0 Optional.
